Grip Seal Ring

Grip Seal Ring
Grip Seal Ring
Send Inquiry
Product Code : 5555
Brand Name : L. V. LOCKING DEVICES
Price And Quantity
  • Minimum Order Quantity
  • 250
  • Unit of Measure
  • Piece/Pieces
  • Price
  • 1.25 - 20EACH INR
Product Specifications
  • Hardness
  • 45 - 50 HRC
  • Tolerance
  • +/-0.10 Millimeter (mm)
  • Material
  • Spring Steel, Stainless Steel
  • Style
  • Other
Product Description

Grip Seal Ring is designed for the use on shafts which do not have retainer ring groove. This ring has great force so you can secure your motor even if it does not have retainers. Designed to produced to exacting tolerances, these  rings are especially strong and made of fiber-reinforced polycarbonate. Reasonable cost and engineered to last, this ring is available in different colors and sizes. Apart from  all these Grip Seal Ring, can be purchased by our customers at market leading rates.

Features:

  • Excellent functionality
  • Simple maintenance
  • Durable finish standards
  • Longer service life

Specification :

Nominal dimension

RING

Shaft dia d1 h 11

S

d3

a ~

b ~

d5

Weight (kg /1,000)

Max.load
(kg)

1.5

0.40

1.40

1.7

0.7

0.9

0.02

4.0

2.0

0.60

1.90

1.7

1.0

0.9

0.03

5.0

2.5

0.60

2.35

1.7

1.2

0.9

0.04

6.0

3.0

0.60

2.85

1.9

1.4

0.9

0.05

7.5

3.5

0.60

3.30

2.1

1.6

0.9

0.08

9.0

4.0

0.80

3.80

2.7

1.8

1.3

0.17

10.0

4.5

0.80

4.25

3.0

2.0

1.3

0.22

12.0

5.0

0.80

4.75

2.6

2.2

1.3

0.26

13.0

6.0

1.00

5.70

3.0

2.5

1.3

0.38

17.0

7.0

1.00

6.70

3.2

2.8

1.3

0.48

18.0

8.0

1.20

7.70

3.3

3.0

1.3

0.55

20.0

9.0

1.20

8.65

3.0

3.3

1.5

0.75

23.0

10.0

1.20

9.65

3.0

3.5

1.5

0.96

25.0

11.0

1.20

10.60

3.6

4.2

1.7

1.25

28.0

12.0

1.20

11.60

3.6

4.7

1.7

1.50

30.0

13.0

1.20

12.55

4.0

5.0

1.7

1.80

32.0

13.8

1.50

13.30

4.6

5.4

2.0

2.65

35.0

14.0

1.50

13.50

4.6

5.4

2.0

2.60

35.0

15.0

1.50

14.50

4.8

5.7

2.0

2.80

40.0

16.0

1.50

15.40

4.9

5.9

2.0

3.20

50.0

17.0

1.75

16.35

6.0

6.3

2.5

4.80

60.0

18.0

1.75

17.30

6.0

6.7

2.5

5.20

70.0

20.0

1.75

19.30

6.0

7.1

2.5

6.00

75.0

22.0

1.75

21.20

6.0

7.4

2.5

6.50

80.0

24.0

1.75

23.15

6.5

7.8

2.5

6.80

85.0

25.0

1.75

24.15

6.5

8.2

2.5

7.00

90.0
